Tubing Sleeve PEEK Natural 1/16″ OD x .031 x 1.3″

SKU: F-232 Categories: 1/16" OD PEEK Tubing Sleeves, Fittings, Tubing Sleeves

Description
Specifications

Description

This PEEK Tubing Sleeve designed specifically for connecting capillary tubing to standard 10-32 ports. Manufactured from biocompatible PEEK it offers excellent chemical resistance. It does require the use of a wrench tightened stainless steel nuts. It comes in natural color. Brochure

Additional information

Color	Natural
For Tubing OD (µm)	730-770
Length (in)	1.3
Material	PEEK
Pressure Rating Max (bar)	414
Pressure Rating Max (psi)	6000
Tubing Sleeve ID (in)	0.031
Tubing Sleeve OD (in)	1/16
