Runge Mikron miniature detectors
Small & modular – robust & intelligent
The range of Runge Mikron detectors from Biotech Fluidics, unites many attractive features in a tiny package. Different modules can be combined to measure in a variety of fluidic systems, including liquid chromatography.
Thanks to several available LED-based fixed- wavelength light sources with a life-time of more than 5000 hours, power consumption below 2.5 watts, and start-up within seconds, the Runge Mikron detectors are ideal for incorporation into portable field instruments and online monitoring devices. This also allows the detectors to be operated in refrigerated laboratory environments down to 4 °C (39 °F), without virtually any heat production. Flexibility in sampling frequencies, detector cell sizes, port connections and choice of wetted materials, make the Runge Mikron detectors suitable for many flow rate conditions and eluent compositions.
The Runge Mikron detectors are easy to connect as they communicate through, and draw power from, one single USB-C port. Drivers are provided for several chromatography software, alternatively, an open protocol can be used for customised implementation. The detectors conform to international standards and are CE marked.
Features
Small
With a diameter of only 32 mm (1.3″) the Runge Micron detectors fits everywhere. Mount it on the side of your system or on a laboratory stand.
Flexible
Light sources, filters and measuring can be adapted to changing tasks. Ideal solution for changing routine tasks, yet more affordable and compact than a traditional fully variable detector.
Future-proof
Technical progress in LEDs is ongoing – with the mikron you can be part of it, eaven after two or five years.
Connective
USB-C connector for data and energy, drivers for Data Apex Clarity, SCPA ChromStar, SCPA PrepCon, LabVIEW, open Runge protocol for customized implementation.
Product range
Absorbance detector
mikron 31 photometer
The mikron 31 is the photometer you can take to the measurement site an not vice versa. It simultaneously takes measurements on one or two wavelengths (rapid scanning).
It can be used directly in chilled environments down to 4°C (39°F) and its optical design with a reference channel guarantees a high degree of accuracy with no external calibration.
Fluorescence detector
mikron 71 fluorimeter
The mikron 71 is the first pocket model fluorimeter in the world. The detector comes with a fixed but exchangeable wavelengths for simulation and emission.
Thanks to the LED light source, can it be used directly in a chilled setting att 4 °C (39°F) in bioanalysis. The reference channel ensures a high degree of accuracy with no external calibration.
Conductivity detector
mikron 81 conductivity meter
Thanks to its size the mikron 81 conductivity meter can be used at the measurement site. It has a broad measurement range of five decades which can be adjusted even more accurately to your requirements by selecting the appropriate measuring cell.
The detector can be used in chilled environments down to 4°C (39°F). The internal measurement resistance calibrates itself every time it is switched on and when instructed. It also automatically identifies the cell constant of existing measuring cells.
