Flangeless™ fittings
Cost-efficient fittings that are easy to use
The IDEX Flangeless™ Fittings are easy to use, provide adequate sealing in many situations, and are available for several flat-bottom port designs and many different tubing outer diameters. These fittings eliminate the need to flanged tubing and are a cost-effective alternative due to their few components and quick replacement.
The Flangeless™ Fittings system has a wide selection of nuts for the popular 1/4-28 and M6x1 port designs, and some nuts are even provided in different colours. Nuts are also available for the narrower 10-32 flat-bottom ports, plus large bore versions for 5/16-24 and 1/2-20 port threads. The nuts come with different head designs to accommodate a variety of assembly situations, and are manufactured from either the polymeric materials Delrin (an acetal polymer also known as polyoxymethylene, POM), PEEK, ETFE, PPS, PFA, PP, or stainless steel.
The ferrules for the Flangeless™ Fittings system are made from ETFE and can accommodate an unmatched range of tubing outer diameters including 1/16”, 1/8”, 3/16”, 1/4”, and 5/16”, plus metric sizes 1.8, 2.0, 2.5, 3.0, and 4.0 mm. In addition, a special low-profile ferrule for 1/4-28 ports is also available for 1/16” and 1/8” OD tubing, which can be especially suitable for shallow receiving ports such as those used on some low-pressure valves.
The pressure rating depends on tubing diameter, port design, and type of ferrule used, and range from 250 psi (17 bar) up to 2500 psi (172 bar) for the Flangeless™ Fittings. In tests, it has been shown that the ideal amount of torque to achieve expected part performance should be approximately 3–4 in-lbs (0.34–0.45 N·m).
Popular choices
Product details
Ferrules for 1/16″ & 1/8″ tubing
| Part No.* | Description | Port | Pressure Rating | Material |
|---|---|---|---|---|
| P-200 | Flangeless Ferrule for 1/16” OD Tubing | M6 or 1/4-28 Flat-Bottom | 2,000 psi (138 bar) | ETFE Blue |
| P-200N | Flangeless Ferrule for 1/16” OD Tubing | M6 or 1/4-28 Flat-Bottom | 2,000 psi (138 bar) | ETFE Natural |
| P-240 | Flangeless Ferrule for 1/16” OD Tubing, Small valve | M6 or 1/4-28 Flat-Bottom | 2,500 psi (172 bar) | ETFE Natural |
| P-300 | Flangeless Ferrule for 1/8” OD Tubing | M6 or 1/4-28 Flat-Bottom | 500 psi (34 bar) | EFTE Yellow |
| P-300N | Flangeless Ferrule for 1/8” OD Tubing | M6 or 1/4-28 Flat-Bottom | 500 psi (34 bar) | ETFE Natural |
| P-340 | Flangeless Ferrule for 1/8” OD Tubing, Small valve | M6 or 1/4-28 Flat-Bottom | 500 psi (34 bar) | ETFE Natural |
Ferrules for 1.8, 2.0, 2.5, 3.0, 4.0 mm tubing OD
| Part No.* | Description | Port | Pressure Rating | Material |
|---|---|---|---|---|
| F-252 | 1/16” OD Tubing Sleeve for 1.0 mm ID Tubing | M6 or 1/4-28 Flat-Bottom | 500 psi (34 bar) | FEP Purple |
| P-342 | Flangeless Ferrule for 1.8 mm OD Tubing | M6 or 1/4-28 Flat-Bottom | 500 psi (34 bar) | ETFE Green |
| P-363R | Flangeless Ferrule for 2.0 mm OD Tubing | M6 or 1/4-28 Flat-Bottom | 500 psi (34 bar) | ETFE Red |
| P-353 | Flangeless Ferrule for 2.5 mm OD Tubing | M6 or 1/4-28 Flat-Bottom | 500 psi (34 bar) | ETFE Natural |
| P-343 | Flangeless Ferrule for 3.0 mm OD Tubing | M6 or 1/4-28 Flat-Bottom | 500 psi (34 bar) | ETFE Orange |
| P-344 | Flangeless Ferrule for 4.0 mm OD Tubing | 5/16-24 Flat-Bottom | 250 psi (17 bar) | ETFE Natural |
Nuts for 1/4-28 ports
| Part No.* | Description | Port | Pressure Rating | Head Style | Material |
|---|---|---|---|---|---|
| F-358 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | FlushNut | SST |
| LT-111 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | PEEK Natural |
| P-201 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | Delrin Black |
| P-202 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | Delrin Red |
| P-218 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | ETFE Natural |
| P-230 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | PEEK Natural |
| P-235 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Short Standard Knurl | PEEK Natural |
| P-238 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | Delrin Purple |
| P-245 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | PFA Natural |
| P-286 | Flangeless Nut for 1/16” OD Tubing | 1/4-28 Flat Bottom | ** | Headless Knurl | PPS Natural |
| F-368 | Flangeless Fitting for 1/8” OD Tubing | 1/4-28 Flat Bottom | ** | FlushNut | SST |
| P-301 | Flangeless Fitting for 1/8” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | Delrin Black |
| P-302 | Flangeless Fitting for 1/8” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | Delrin Red |
| P-305 | Flangeless Fitting for 1/8” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | Delrin Green |
| P-308 | Flangeless Fitting for 1/8” OD Tubing | 1/4-28 Flat Bottom | ** | Short Standard Knurl | Delrin Black |
| P-315 | Flangeless Fitting for 1/8” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | ETFE Natural |
| P-330 | Flangeless Fitting for 1/8” OD Tubing | 1/4-28 Flat Bottom | ** | Standard Knurl | PEEK Natural |
| P-335 | Flangeless Fitting for 1/8” OD Tubing | 1/4-28 Flat Bottom | ** | Short Standard Knurl | PEEK Natural |
Nuts for M6x1 ports
| Part No.* | Description | Port | Pressure Rating | Head Style | Material |
|---|---|---|---|---|---|
| P-207 | Flangeless Nut for 1/16” OD Tubing | M6 Flat-Bottom | ** | Standard Knurl | Delrin Black |
| P-207S | Flangeless Nut for 1/16” OD Tubing | M6 Flat-Bottom | ** | Short Standard Knurl | Delrin Black |
| P-247 | Flangeless Nut for 1/16” OD Tubing | M6 Flat-Bottom | ** | Short Standard Knurl | PEEK Black |
| P-307 | Flangeless Nut for 1.8 mm to 1/8” OD Tubing | M6 Flat-Bottom | ** | Standard Knurl | Delrin Black |
| P-307S | Flangeless Nut for 1.8 mm to 1/8” OD Tubing | M6 Flat-Bottom | ** | Short Standard Knurl | Delrin Black |
| P-347 | Flangeless Nut for 1.8 mm to 1/8” OD Tubing | M6 Flat-Bottom | ** | Short Standard Knurl | PEEK Black |
Nuts and ferrules for 5/16-24 and 1/2-20 ports
| Part No.* | Description | Port | Pressure Rating | Head Style | Material |
|---|---|---|---|---|---|
| P-136 | Flangeless Nut for 1/16” OD tubing | 5/16-24 Flat-Bottom | ** | Standard Knurl | PEEK Natural |
| P-130 | Flangeless Nut for 1/8” OD tubing | 5/16-24 Flat-Bottom | ** | Standard Knurl | PEEK Natural |
| P-132 | Flangeless Nut for 3/16” OD tubing | 5/16-24 Flat-Bottom | ** | Standard Knurl | PEEK Natural |
| U-655 | Flangeless Nut for 1/4” OD tubing | 1/2-20 Flat-Bottom | ** | Large Knurl | PEEK Black |
| U-662 | Flangeless Nut for 5/16” OD tubing | 1/2-20 Flat-Bottom | ** | Large Knurl | PEEK Black |
| P-133 | Flangeless Ferrule for 3/16” OD tubing | 5/16-24 Flat-Bottom | 500 psi (34 bar) | - | ETFE Blue |
| P-133N | Flangeless Ferrule for 3/16” OD tubing | 5/16-24 Flat-Bottom | 500 psi (34 bar) | - | ETFE Natural |
| U-650 | Flangeless Ferrule for 1/4” OD tubing | 1/2-20 Flat-Bottom | 250 psi (17 bar) | - | ETFE Natural |
| U-660 | Flangeless Ferrule for 5/16” OD tubing | 1/2-20 Flat-Bottom | 250 psi (17 bar) | - | ETFE Natural |
Product guide
Match Flangeless™ ferrule and nut with your tubing OD
| Tubing OD | Flat-bottom port | Ferrules | Nuts |
|---|---|---|---|
| 1/16" | M6x1 | P-200, P-840 | P-207, P-207S, P-247, P-931 |
| 1/16" | 1/4-28 | P-200, P-840 | Any 1/4-28 nut for 1/16” OD tubing |
| 1/16" | 5/16-24 | P-200 | P-136 |
| 1/8" | M6x1 | P-300, P-940 | P-307, P-307S, P-347, P-945 |
| 1/8" | 1/4-28 | P-300, P-940 | Any 1/4-28 nut for 1/8” OD tubing |
| 1/8" | 5/16-24 | P-300 | P-130 |
| 3/16" | 5/16-24 | P-133 | P-132 |
| 1/4" | 1/2-20 | U-650 | U-655 |
| 5/16" | 1/2-20 | U-660 | U-662 |
| 1.0 mm | M6x1 | P-200* | P-207, P-207S, P-247 |
| 1.0 mm | 1/4-28 | P-200* | Any 1/4-28 nut for 1/16” OD tubing |
| 1.8 mm | M6x1 | P-242 | P-307, P-307S, P-347 |
| 1.8 mm | 1/4-28 | P-242 | Any 1/4-28 nut for 1/8” OD tubing |
| 2.0 mm | M6x1 | P-363R | P-307, P-307S, P-347 |
| 2.0 mm | 1/4-28 | P-363R | Any 1/4-28 nut for 1/8” OD tubing |
| 2.5 mm | M6x1 | P-353 | P-307, P-307S, P-347 |
| 2.5 mm | 1/4-28 | P-353 | Any 1/4-28 nut for 1/8” OD tubing |
| 3.0 mm | M6x1 | P-343 | P-307, P-307S, P-347 |
| 3.0 mm | 1/4-28 | P-343 | Any 1/4-28 nut for 1/8” OD tubing |
| 4.0 mm | 5/16-24 | P-344 | P-132 |
| *with F-252 sleeve, not included | |||
Resources
Consult the Periodic Table of Analytical Fittings for a quick overview, the Fittings 101 for guidance and learning, and the IDEX Catalogue for product details, or contact Biotech Fluidics for expert advice.
